Matatu-chikamu matatu-waya kabhodhi-mhando inoshanda haronic filter
Galla inokupa iwe yakanakisa matatu-chikamu matatu-waya kabhoni-mhando inoshanda yeHarmonic Filter Solutions yako. Inoshandisa Dhijitari Kudzora, ine modular cabinet dhizaini & inobatanidza kusvika kune iyo 50th Harmonic. Yakanakira nzvimbo dze data, nharaunda dzemaindasitiri, uye simba rinovandudza.
Iyo nhatu-chikamu-chivha-waya kabhoni-type inoshanda filter (APF) inopa mafambiro epamberi peHarmonic yehurongwa hwematanho matatu-matatu-waya masisitimu. Kushandisa DPLI + CPLD Digital Kudzora uye matatu-mwero-temology, iyi APF inopa chaiyo yekubatanidza ikozvino kuripirwa kusvika kune makumi mashanu emari. Yayo Modular dhizaini inotsigira yakafanana yekubatanidza kune inokatyamadza kugona. Iyo yakasimba kabari clendem uye yakazvimirira mhepo ducts inoona yakavimbika kushanda. Inowanika muVoltage Yazvino uye Zvazvino Ratings, iyo Matanho matatu-WIRE Cabinet-Type Active Acaronic Filter Inobudirira Kunovandudza Mhando Dzemhando Mune Zvekushandisa.
For mod tsanangudzo:
| GY | Ahf | 0.4 | 50a | / | 3l | C |
| Enterprise kodhi | Active Harmonic Filter | Voltage level 0.22: 220V 0.4: 380V ± 20% 0.5: 500V】 20% 0.69: 690V ± 20% |
Rated Capacity (KVAR) 25/50/75 / 100 / 150A | 3L: Matanho matatu-matatu-waya | C: Cabinet |
Zvimiro:
● Shandisa DPLLI + CPLD Tese Dhijitari Control Core, matatu-level Topology Tekinoroji, Advanced Kuwanikwa Algorithm uye PWM Control Trategy Kuwana Kubhadharwa Kwechokwadi kweHarmonic Yazvino.
● Kutora modular dhizaini, iyo inofambisa yakaenzana yekubatanidza module yakawanda, inotora nzvimbo diki uye iri nyore kuchengetedza.
● Kugadzirwa kwechimiro kwemweya wakazvimirira madhiri uye warechi akazvimirira anosimbisa kushanda kwakasimba kwemidziyo.
.
● Iyo Harmonic firiting rate yakakwira. Kana kugona kuchitendera, iyo Harmonic ikozvino kuwanda kweiyo rate inogona kuve yakakwira se 95%. Seta 100% yazvino kudzikisira kuburitsa kuti ive nechokwadi chekutenderera kwenguva refu yekushanda kwemidziyo.
Zvishandiso:
Matatu--chikamu-matatu-waya kabhoni-mhando inoshanda maLarters mafirita akaiswa mumhando dzakasiyana siyana dzekurasa distonsic distorttion:
● Data nzvimbo:Inochengetedza inotaridzika inokwana
● Nharaunda dzeindasitiri:Kuvandudza masimba emhando kune matatu-chikamu-cheya-wire michina uye maitiro, kusimudzira kushanda zvakanaka uye kuvimbika.
● Kugadzira zvidyarwa:Kuderedza kusawirirana zvinogadzirwa nekukasira mari yekufambisa madhiri (VFDS) uye zvimwe zvisiri-mitsara mitoro.
● Mafuta negesi Indasitiri:Kuverengera yakagadzikana simba rekugovera munzvimbo dzinodaidzira neyemukati memoconic zvemukati.
● Inovandudza simba masisitimu:Kubatanidza gadziriso yekuvandudza simba zvinobudirira nekudzora nyaya dzehondo.
Matatu--chikamu-matatu-Wire kabhoni-mhando inoshanda mafirita anopa mhinduro yakatarwa yekuwedzera simba mamiriro uye zvigadzirwa zvemidziyo mune matatu-chikamu-matatu-waya system.
Technical parameter:
| 220V Series | 380V Series | 500V Series | 690V Series | ||
| Altitude | <2000m, pamusoro 2000m, funga maererano neGB / T3859.2 | ||||
| Ambient tembiricha | -20 ~ + 50 ℃ | ||||
| Hunyoro Hunyoro | ≤90%, hapana concensation pane iyo nzvimbo kana iyo mwedzi madiki tembiricha iri 25 ℃ | ||||
| Kusvibisa level | Level iii pazasi | ||||
| Inoshanda voltage | Ac220V ± 20% | Ac380V ± 20% | Ac500v】 20% | Ac690V ± 20% | |
| Kushanda frequency | 50hz ± 5% | ||||
| Muripo wazvino | 25a | 25/50/75/100 / 150a | 100a | 100a | |
| Grid chimiro | L / n | 3P3W / 3P4W | 3P3W / 3P4W | 3P3W / 3P4W | |
| Nhamba yezvikamu yakabatana mukufananidza |
Ulimited | ||||
| Kuwedzeredza Kwemuchina Kubudirira | ≥97% | ||||
| Grid chimiro | 32khz | 16khz | 12.8khz | 12.8khz | |
| Kuroverwa Range | 2 ~ 50times, imwe chete yekushambadzira chiyero chinogadziriswa | ||||
| Sarudzo yekusarudzwa | Simba Resimba | Inoshanda simba, simba rinogadzirisa + asymmetry | |||
| Simba Resimba Rwiyo rwekutsiva |
≥95% | > 92% | |||
| Neutral Kucheka kugona |
Neutral mutsetse wekushandura kugona ndeye 3 times ayo ekuchinjika kwechikamu chekugona | ||||
| Nguva yakazara yekupindura | <10ms | <40ms | <40ms | <40ms | |
| Ruzha | ≤60db | ≤60db | ≤65DB | ≤65DB | |
| Dzora nzira | 2-Nzira yeRs 485 interface (Zvinotsigira GPRS / WIFI) | ||||
| Dziviriro | Kupfuura | Kupfuura | |||
| Kuisa nzira | Rack / Wall-Yakakwidzwa | Rack | |||
| Mutsara unouya | Kudzokera Kuuya (Rack Type), Upper Kuuya (Wall-Yakakwira) | Back iningcome mutsara | |||
| Danho redziviriro | IP20 | ||||
Model & Kufunga:
| Cabinet mudziyo modhi | ||||
|---|---|---|---|---|
| Model nhamba | Compensation Capacity (kvar) | Sistimu Voltage (v) | Zvidimbu (D * W * H) | Nzira inotonhorera |
| GY APF-0.4-100A / 4L-C | 100 | 380 × 20% | 800 * 1000 * 2200mm | Kumanikidzwa mweya kutonhora |
| GY APF-0.4-150A / 4L-C | 150 | 380 × 20% | 800 * 1000 * 2200mm | |
| GY APF-0.4-200A / 4L-C | 200 | 380 × 20% | 800 * 1000 * 2200mm | |
| GY APF-0.4-250A / 4L-C | 250 | 380 × 20% | 800 * 1000 * 2200mm | |
| GY APF-0.4-300A / 4L-C | 300 | 380 × 20% | 800 * 1000 * 2200mm | |
| GY APF-0.4-400A / 4L-C | 400 | 380 × 20% | 800 * 1000 * 2200mm | |
| GY APF-0.5-300A / 4L-C | 300 | 500 × 20% | 800 * 1000 * 2200mm | |
| GY APF-0.69-300A / 4L-C | 300 | 690 × 20% | 800 * 1000 * 2200mm | |
