690V kabhodhi-mhando inoshanda haronic filter
Giya ndeye 690V kabhodhi-mhando inoshanda yeHarmonic filter mugadziri uye mutengesi muChina. Inoratidza Dhijitari Control, Modular Dhizaina & Inobatanidza Kusvikira kune makumi mashanu Harmonic, kururamisa kusimba. Yakanakira pakati pepakati-voltage masisitimu, indasitiri inorema, uye michina yekubhadhara. Zadza fomu redu ikozvino kugamuchira Prompt quote yezvinodiwa zvako zvekutenga!
Iyo 690V kabhoni-mhando inoshanda Iyi APF inoshandisa yepamusoro DPLI + CPLD Digital Kudzora uye matatu-level tipology yePreecise yeRocising Commonation kusvika kune makumi mashanu Harmonic, panguva imwe chete kugadzirisa zvinhu zvitatu-chikamu. Iyo Modular dhizaini inotsigira inoisiririsa kugona nekugonesa kubatana kwakafanana kwekubatana kwezvikamu zvakawanda. Kugara mune yakazvimba kabhadheni nemhepo yakazvimirira mhepo, iyo 690V kabhodhi-mhando inoshanda yeFilter inovimbisa kushanda kwakavimbika uye kureruka kwakareruka. Nezvazvinowanikwa zvarino zvarini kusvika 300A uye KVAR MABHUKU kusvika 300, iyi apf inoburitsa inoshanda simba rekuvandudza kwemasanganiswa e690V.
For mod tsanangudzo:
| GY | Ahf | 0.69 | 100a | / | 4l | C |
| Enterprise kodhi | Active Harmonic Filter | Voltage level 0.69: 690V ± 20% |
Rated Capacity (KVAR) 100A | 3L: Matanho matatu-matatu-waya 4l: nhatu-chikamu ina-waya |
C: Cabinet |
Zvimiro:
● Shandisa DPLLI + CPLD Tese Dhijitari Control Core, matatu-level Topology Tekinoroji, Advanced Kuwanikwa Algorithm uye PWM Control Trategy Kuwana Kubhadharwa Kwechokwadi kweHarmonic Yazvino.
● Kutora modular dhizaini, iyo inofambisa yakaenzana yekubatanidza module yakawanda, inotora nzvimbo diki uye iri nyore kuchengetedza.
● Kugadzirwa kwechimiro kwemweya wakazvimirira madhiri uye warechi akazvimirira anosimbisa kushanda kwakasimba kwemidziyo.
.
● Iyo Harmonic firiting rate yakakwira. Kana kugona kuchitendera, iyo Harmonic ikozvino kuwanda kweiyo rate inogona kuve yakakwira se 95%. Seta 100% yazvino kudzikisira kuburitsa kuti ive nechokwadi chekutenderera kwenguva refu yekushanda kwemidziyo.
Zvishandiso:
690V kabhodhi-mhando inoshanda macarters yakanakira kune kuvandudza simba remhando mune yepakati-voltage maindasitiri marongero:
● Pakati-voltage simba masisitimu:Simbisa kugoverwa kwemagetsi mu 690V network, kuderedza kusawirirana uye kugadzirisa maitiro ekubudirira system.
● Nzvimbo Dzakakura Industrial:Kuona kuvimbika kuvimbika kwemidziyo yakadzama mumaindasitiri ane akakosha kuHarmonic mitoro, akadai semigodhi, mafuta negesi, uye petrochemicals.
● Pakati-voltage mota inotyaira:Kuderedza kuderedza maAkonic manhamba akagadzirwa neakakura mota drives, kuderedza voltage kukanganisa uye kugadzirisa mota kuita.
● Marine uye Offshore Puratifomu:Kupa hunhu hwakasimba uye hwakavimbika hwemagetsi munzvimbo dzine hutsinye uko 690V masisitimu akajairika.
690V kabhodhi-mhando inoshanda macarters inopa mhinduro yakakwirira-yekuita yekugadzirisa simba kune simba mukuda 690V application.
Technical parameter:
| 220V Series | 380V Series | 500V Series | 690V Series | ||
| Altitude | <2000m, pamusoro 2000m, funga maererano neGB / T3859.2 | ||||
| Ambient tembiricha | -20 ~ + 50 ℃ | ||||
| Hunyoro Hunyoro | ≤90%, hapana concensation pane iyo nzvimbo kana iyo mwedzi madiki tembiricha iri 25 ℃ | ||||
| Kusvibisa level | Level iii pazasi | ||||
| Inoshanda voltage | Ac220V ± 20% | Ac380V ± 20% | Ac500v】 20% | Ac690V ± 20% | |
| Kushanda frequency | 50hz ± 5% | ||||
| Muripo wazvino | 25a | 25/50/75/100 / 150a | 100a | 100a | |
| Grid chimiro | L / n | 3P3W / 3P4W | 3P3W / 3P4W | 3P3W / 3P4W | |
| Nhamba yezvikamu yakabatana mukufananidza |
Ulimited | ||||
| Kuwedzeredza Kwemuchina Kubudirira | ≥97% | ||||
| Grid chimiro | 32khz | 16khz | 12.8khz | 12.8khz | |
| Kuroverwa Range | 2 ~ 50times, imwe chete yekushambadzira chiyero chinogadziriswa | ||||
| Sarudzo yekusarudzwa | Simba Resimba | Inoshanda simba, simba rinogadzirisa + asymmetry | |||
| Simba Resimba Rwiyo rwekutsiva |
≥95% | > 92% | |||
| Neutral Kucheka kugona |
Neutral mutsetse wekushandura kugona ndeye 3 times ayo ekuchinjika kwechikamu chekugona | ||||
| Nguva yakazara yekupindura | <10ms | <40ms | <40ms | <40ms | |
| Ruzha | ≤60db | ≤60db | ≤65DB | ≤65DB | |
| Dzora nzira | 2-Nzira yeRs 485 interface (Zvinotsigira GPRS / WIFI) | ||||
| Dziviriro | Kupfuura | Kupfuura | |||
| Kuisa nzira | Rack / Wall-Yakakwidzwa | Rack | |||
| Mutsara unouya | Kudzokera Kuuya (Rack Type), Upper Kuuya (Wall-Yakakwira) | Back iningcome mutsara | |||
| Danho redziviriro | IP20 | ||||
Model & Kufunga:
| Cabinet device model | ||||
|---|---|---|---|---|
| Model nhamba | Compensation Capacity (kvar) | Sistimu Voltage (v) | Zvidimbu (D * W * H) | Nzira inotonhorera |
| GY APF-0.4-100A / 4L-C | 100 | 380 × 20% | 800 * 1000 * 2200mm | Kumanikidzwa mweya kutonhora |
| GY APF-0.4-150A / 4L-C | 150 | 380 × 20% | 800 * 1000 * 2200mm | |
| GY APF-0.4-200A / 4L-C | 200 | 380 × 20% | 800 * 1000 * 2200mm | |
| GY APF-0.4-250A / 4L-C | 250 | 380 × 20% | 800 * 1000 * 2200mm | |
| GY APF-0.4-300A / 4L-C | 300 | 380 × 20% | 800 * 1000 * 2200mm | |
| GY APF-0.4-400A / 4L-C | 400 | 380 × 20% | 800 * 1000 * 2200mm | |
| GY APF-0.5-300A / 4L-C | 300 | 500 × 20% | 800 * 1000 * 2200mm | |
| GY APF-0.69-300A / 4L-C | 300 | 690 × 20% | 800 * 1000 * 2200mm | |
